bayprior

bayprior: Bayesian Prior Elicitation for Clinical Trials
R version Shiny golem GPL-3 R CMD check renv Lifecycle Docs Live app

Overview

bayprior is an advanced interactive R package and Shiny application designed for biostatisticians and clinical researchers to implement Bayesian Prior Elicitation, Conflict Diagnostics, and Sensitivity Analysis for clinical trials.

The package addresses the upstream problem that existing Bayesian trial packages (trialr, RBesT, hdbayes) largely ignore: how do you construct, validate, and justify your prior to a regulator? The FDA’s 2026 draft guidance on Bayesian methods makes this a live, urgent need — with no unified R tool previously addressing it.

bayprior enables users to:

  • Elicit structured priors — SHELF-style quantile matching, moment matching, and the interactive roulette method across Beta, Normal, Gamma, Log-Normal, Exponential, and Weibull families.
  • Aggregate expert opinions — Linear or logarithmic pooling of multiple expert priors with pairwise Bhattacharyya agreement diagnostics and cross-family compatibility validation.
  • Diagnose prior-data conflict — Box’s p-value, surprise index, Bhattacharyya overlap, and multivariate Mahalanobis distance, supporting binary, continuous, Poisson/count, and survival data types.
  • Quantify sensitivity — Posterior conclusions evaluated across hyperparameter grids via tornado plots and influence heatmaps, with independent data entry.
  • Build robust priors — Sceptical, robust mixture, and calibrated power priors for regulatory sensitivity analyses.
  • Generate regulatory reports — Self-contained HTML, PDF, or Word (.docx) prior justification reports aligned with FDA/EMA submission expectations, rendered via Quarto.

Features and Modules

Module Detail Primary Output Goal
Prior Elicitation Quantile matching, moment matching, SHELF roulette for Beta / Normal / Gamma / Log-Normal / Exponential / Weibull Fitted density plot + parameter table Structured expert prior elicitation
Expert Pooling Linear and logarithmic opinion pooling with support compatibility validation Consensus density overlay + Bhattacharyya matrix Aggregate multi-expert beliefs
Conflict Diagnostics Box p-value, surprise index, KL divergence, Bhattacharyya overlap; binary, continuous, Poisson, and survival data Prior–Likelihood–Posterior overlay Detect prior misspecification
Mahalanobis Check Two-endpoint multivariate conflict test Chi-sq p-value + per-parameter z-scores Co-primary endpoint trials
Sensitivity Analysis Hyperparameter grid over posterior mean, SD, CrI width, Pr(efficacy); independent data entry Tornado plot + influence heatmap Demonstrate robustness to regulators
Sceptical Prior Spiegelhalter–Freedman centred-at-null prior Prior density + summary statistics Conservative regulatory sensitivity
Robust Mixture Schmidli et al. MAP robust mixture prior Robust vs informative density overlay Protection against misspecification
Power Prior Ibrahim–Chen calibrated borrowing weight via Bayes Factor Calibration curves + optimal δ Principled historical data borrowing
Export Report HTML / PDF / Word (.docx) prior justification document via Quarto Regulatory-ready self-contained report FDA/EMA submission documentation

Core Methodology

Prior Elicitation

Three structured elicitation approaches are implemented. Quantile matching fits a parametric distribution to expert-specified probability–value pairs via numerical optimisation. Moment matching derives hyperparameters analytically from an expert-supplied mean and SD. The SHELF roulette method (Oakley & O’Hagan, 2010) lets the expert allocate chips across histogram bins, fitting a parametric family to the chip allocation in real time.

All three methods support six distribution families:

Family Support Typical use
Beta (0, 1) Response rates, proportions
Normal (−∞, ∞) Mean differences, log odds ratios
Gamma (0, ∞) Event rates, variances, survival times
Log-Normal (0, ∞) Hazard ratios, PK parameters
Exponential (0, ∞) Constant hazard rates, Poisson rate priors
Weibull (0, ∞) Non-constant hazard survival times (OS, PFS)

Exponential priors support "moments", "rate", and "quantile" methods. Weibull priors support "moments", "params", and "quantile" methods.

Prior-Data Conflict Diagnostics

Conflict detection follows Box (1980). Four complementary metrics are computed:

  • Prior predictive p-value — tests whether observed data is plausible under the prior predictive distribution.
  • Surprise index — standardised distance between prior mean and observed data.
  • Bhattacharyya overlap — distributional overlap between prior and normalised likelihood.
  • KL divergence — information-theoretic distance from prior to likelihood.

Four data types are supported:

Data type Conjugate update Typical endpoint
Binary (x events / n) Beta–Binomial Response rate, ORR
Continuous (mean, SD, n) Normal–Normal Mean difference, HbA1c
Poisson / count (events / exposure) Gamma–Poisson Adverse event rate
Survival (events / follow-up time) Gamma–Exponential Hazard rate, OS, PFS

Validation and Compatibility Checks

bayprior includes a comprehensive validation layer:

  • Prior–data compatibility — warns when a prior family is atypical for the selected data type.
  • Pooling compatibility — blocks pooling of distributions with incompatible supports; warns for same-support cross-family pooling.
  • Sensitivity compatibility — warns for single-parameter families and cross-family mixture grids; blocks incompatible-support mixtures.

Sensitivity Analysis

The sensitivity module is fully independent of conflict diagnostics — users can enter observed data directly without running conflict diagnostics first. Results are visualised as tornado plots and influence heatmaps. A dedicated sensitivity_cri() function tracks credible interval width specifically — a key regulatory quantity.

Robust and Power Priors

The robust mixture prior (Schmidli et al., 2014) mixes the informative prior with a vague Normal component. The sceptical prior (Spiegelhalter & Freedman, 1994) is centred at the null treatment effect. The power prior (Ibrahim & Chen, 2000) down-weights historical data by δ ∈ (0, 1], calibrated to achieve a target Bayes Factor.

User Interface

The Shiny app includes a dark / light mode toggle persisted via browser localStorage. All module outputs reset automatically when inputs change, preventing stale results from being shown alongside new inputs.

Prior Elicitation Panel

  • Distribution family: Beta, Normal, Gamma, Log-Normal, Exponential, or Weibull
  • Elicitation method: Quantile matching, moment matching, or roulette
  • Output reset: Panel resets to placeholder on any input change; active prior indicator stays on until a new prior is explicitly fitted
  • Value boxes: Prior mean, SD, and 95% CrI at a glance

Conflict Diagnostics Panel

  • Data type: Binary, continuous, Poisson/count, or survival
  • Compatibility check: Alert if prior family is atypical for chosen data type
  • Diagnostic statistics: Box p-value, surprise index, and overlap with colour-coded severity

Sensitivity Analysis Panel

  • Independent data entry: Own data type selector with auto-detection from prior family
  • Analysis type: “Posterior quantities” or “Credible interval” with CrI level slider
  • Visualisations: Tornado plot and interactive influence heatmap

Robust Priors Panel

  • Robust mixture: Vague weight slider
  • Sceptical prior: Family and strength selection
  • Power prior: Historical and current data entry; calibration curves

Report Export Panel

  • Format: HTML (self-contained), PDF (xelatex), or Word (.docx)
  • All formats embed figures correctly
  • Single-click render and download

Installation

# Development version from GitHub:
pak::pak("ndohpenngit/bayprior")

# Or (with vignettes):
devtools::install_github("ndohpenngit/bayprior", build_vignettes = TRUE)

PDF reports require Quarto CLI and a LaTeX installation:

install.packages("tinytex")
tinytex::install_tinytex()
# If PDF fails with missing package errors:
tinytex::tlmgr_install(c("tikzfill", "pgf", "tcolorbox", "environ", "pdfcol"))

Reproducible environment (renv)

renv::restore()

Quick Start

library(bayprior)

# ── Elicit a Beta prior ───────────────────────────────────────────────────────
prior <- elicit_beta(mean = 0.35, sd = 0.10, method = "moments",
                     label = "Response rate", expert_id = "Expert_1")
plot(prior)

# ── Elicit an Exponential prior (hazard rate) ─────────────────────────────────
prior_hz <- elicit_exponential(mean = 0.05, method = "moments",
                                label = "Hazard rate")
plot(prior_hz)

# ── Elicit a Weibull prior (OS in months) ─────────────────────────────────────
prior_wb <- elicit_weibull(mean = 20, sd = 10, method = "moments",
                            label = "OS (months)")
plot(prior_wb)

# ── Pool two experts ──────────────────────────────────────────────────────────
e1  <- elicit_beta(mean = 0.30, sd = 0.10, method = "moments", expert_id = "E1",
                   label = "Response rate")
e2  <- elicit_beta(mean = 0.42, sd = 0.12, method = "moments", expert_id = "E2",
                   label = "Response rate")
agg <- aggregate_experts(list(E1 = e1, E2 = e2), weights = c(0.6, 0.4))

# ── Conflict diagnostics — binary data ────────────────────────────────────────
cd <- prior_conflict(prior, list(type = "binary", x = 18, n = 40))
print(cd)

# ── Conflict diagnostics — Poisson / count data ───────────────────────────────
pg <- elicit_gamma(mean = 0.15, sd = 0.06, method = "moments", label = "AE rate")
prior_conflict(pg, list(type = "poisson", x = 12, n = 100))

# ── Conflict diagnostics — survival data ──────────────────────────────────────
prior_conflict(prior_hz, list(type = "survival", x = 20, n = 400))

# ── Sensitivity analysis ──────────────────────────────────────────────────────
sa <- sensitivity_grid(
  prior,
  data_summary = list(type = "binary", x = 18, n = 40),
  param_grid   = list(alpha = seq(1, 8, 0.5), beta = seq(2, 20, 1)),
  target       = c("posterior_mean", "prob_efficacy"),
  threshold    = 0.30
)
plot_tornado(sa)

# ── Robust prior ──────────────────────────────────────────────────────────────
rob  <- robust_prior(prior, vague_weight = 0.20)
scep <- sceptical_prior(null_value = 0.20, family = "beta",
                        strength = "moderate", label = "Response rate (sceptical)")

# ── Generate regulatory report ────────────────────────────────────────────────
prior_report(
  prior           = prior,
  conflict        = cd,
  sensitivity     = sa,
  robust_prior    = rob,
  sceptical_prior = scep,
  output_format   = "html",
  trial_name      = "TRIAL-001",
  sponsor         = "Example Pharma Ltd",
  author          = "N.P., Biostatistician"
)

# ── Launch the Shiny app ──────────────────────────────────────────────────────
run_app()

Vignettes

Vignette Covers
bayprior-introduction Full end-to-end workflow overview
prior-elicitation All six families and three elicitation methods
conflict-diagnostics All four data types; univariate and multivariate
sensitivity-analysis Grid sensitivity, tornado plots, CrI tracking
robust-priors Robust mixture, sceptical, and power priors
regulatory-reporting Report generation, FDA/EMA compliance checklist
browseVignettes("bayprior")

Documentation

Full documentation at ndohpenngit.github.io/bayprior — rendered vignettes, function reference, changelog, and cheat sheet.

References

  • O’Hagan, A. et al. (2006). Uncertain Judgements: Eliciting Experts’ Probabilities. Wiley.
  • Box, G. E. P. (1980). Sampling and Bayes’ inference in scientific modelling and robustness. JRSS-A, 143, 383–430.
  • Oakley, J. E. & O’Hagan, A. (2010). SHELF: the Sheffield Elicitation Framework. University of Sheffield.
  • Schmidli, H. et al. (2014). Robust meta-analytic-predictive priors in clinical trials with historical control information. Biometrics, 70, 1023–1032.
  • Ibrahim, J. G. & Chen, M.-H. (2000). Power prior distributions for regression models. Statistical Science, 15, 46–60.
  • Spiegelhalter, D. J., Freedman, L. S. & Parmar, M. K. B. (1994). Bayesian approaches to randomized trials. JRSS-A, 157, 357–416.
  • FDA (2026). Draft Guidance: Bayesian Statistical Methods for Drug and Biological Products.
